Brake Assembly / Backing Plates

Competitive price and high-quality brake assembly for improved performance

Home > Brake Assembly / Backing Plates

Exceptional quality brake assembly

Features

• Easy to replace and assemble.
• A wide range of load capacity available 2,200 lbs. to 6,000 lbs. per unit.
• Available for electric or hydraulic or mechanic functions
• Hole mounting comes with mounting bolts, nuts, and lock washers are assembled.
• Can be assembled with TOW-MAX brake drums perfictly

Get A Quote

Tow-Max manufactures trailer brakes with exceptional quality and durability to ensure safety on the road, where quality meets customer requirements. The parts are very easy to replace and assemble the user will have no difficulties. Tow-Max has a wide range of working capacity brakes from 2,200 lbs. to 6,000 lbs., which is compatible with any brand.

Specifications

Part Number Description Method Of Operation Hand Type Brake Type Capacity Per Pair
MB092201L 9″x1-3/4″ Brake Assembly Mechanical LH 2200 LBS
MB092201R 9″x1-3/4″ Brake Assembly Mechanical RH 2200 LBS
EB103501L 10″x2-1/4″ Brake Assembly Electric LH 3500 LBS
EB103501R 10″x2-1/4″ Brake Assembly Electric RH 3500 LBS
EB103501LAD 10″x2-1/4″ Brake Assembly Electric LH Self-Adjust 3500 LBS
EB103501RAD 10″x2-1/4″ Brake Assembly Electric RH Self-Adjust 3500 LBS
EB127001L 12″x2″ Brake Assembly Electric LH 7000 LBS
EB127001R 12″x2″ Brake Assembly Electric RH 7000 LBS
EB127001LAD 12″x2″ Brake Assembly Electric LH Self-Adjust 7000 LBS
EB127001RAD 12″x2″ Brake Assembly Electric RH Self-Adjust 7000 LBS
HB092701L 9″x1-3/4″ Brake Assembly Hydraulic LH 2700 LBS
HB092701R 9″x1-3/4″ Brake Assembly Hydraulic RH 2700 LBS
HB103501L 10″x2-1/4″ Brake Assembly Hydraulic LH 3500 LBS
HB103501R 10″x2-1/4″ Brake Assembly Hydraulic RH 3500 LBS
HB103501LFB 10″x2-1/4″ Brake Assembly Hydraulic LH Free Backing 3500 LBS
HB103501RFB 10″x2-1/4″ Brake Assembly Hydraulic RH Free Backing 3500 LBS
HB126001L 12″x2″ Brake Assembly Hydraulic LH 6000 LBS
HB126001R 12″x2″ Brake Assembly Hydraulic RH 6000 LBS
HB126001LFB 12″x2″ Brake Assembly Hydraulic LH Free Backing 6000 LBS
HB126001RFB 12″x2″ Brake Assembly Hydraulic RH Free Backing 6000 LBS
